Compare structures with pLDDT coloring

Superimpose an AlphaFold prediction onto an experimental structure and render both together, with the prediction colored by per-residue pLDDT.

• portein.superimpose_by_alignment() — pairs CA atoms between two structures by re-aligning each structure’s CA-derived sequence to the input alignment, so structures with missing residues are handled transparently.

• portein.by_plddt() — bins residues into AlphaFold’s standard confidence bands, returning a dict shaped for ProteinConfig.highlight_residues.

import tempfile
from pathlib import Path

import matplotlib.pyplot as plt
import yaml
from biotite.sequence import ProteinSequence
from biotite.sequence.align import SubstitutionMatrix, align_optimal
from PIL import Image

import portein

output_dir = Path(tempfile.mkdtemp())

Load the structures

7lc2 is a crystal structure of KRAS bound to a non-hydrolyzable GTP analog (GNP). AF_P01116 is the AlphaFold prediction for the same UniProt entry.

crystal = portein.read_structure("../_data/7lc2.pdb")
af_model = portein.read_structure("../_data/AF_P01116.cif")
crystal_chain_a = crystal[crystal.chain_id == "A"]

Align the input sequences

Build a pairwise alignment of the crystal chain A sequence against the AlphaFold prediction. superimpose_by_alignment will then re-align the structure-derived sequences to this input alignment internally, so missing residues in the crystal structure cause no surprises.

def to_sequence(structure):
    ca = structure[structure.atom_name == "CA"]
    return ProteinSequence("".join(ProteinSequence.convert_letter_3to1(r) for r in ca.res_name))


crystal_seq = to_sequence(crystal_chain_a)
af_seq = to_sequence(af_model)
alignment = align_optimal(crystal_seq, af_seq, SubstitutionMatrix.std_protein_matrix())[0]

Superimpose and bin by pLDDT

superimpose_by_alignment returns the rotated AlphaFold model combined with the crystal structure into one AtomArray. by_plddt reads the AlphaFold b_factor column (where AlphaFold stores pLDDT) and bins each residue into AlphaFold’s standard color bands.

combined, _, paired = portein.superimpose_by_alignment(
    query=crystal_chain_a,
    target=af_model,
    alignment=alignment,
    query_chain="A",
    target_chain_id="B",
    query_chain_id="A",
)

# Color the *target* (now chain "B" in `combined`) by pLDDT.
af_in_combined = combined[combined.chain_id == "B"]
highlight = portein.by_plddt(af_in_combined)
print(f"Superposed using {paired.shape[0]} CA pairs.")

Superposed using 166 CA pairs.

Render the composite

The crystal is plain white but partially transparent so the pLDDT- colored AlphaFold prediction underneath stands out. Per-chain chain_transparency uses PyMOL’s depth-aware cartoon_transparency setting, so the two structures composite correctly per-pixel rather than as flat 2D layers.

with open("../../configs/pymol_settings.yaml") as f:
    pymol_settings = yaml.safe_load(f)

protein_config = portein.ProteinConfig(
    pdb_file=combined,
    rotate=False,
    width=600,
    chain_to_color={"A": "white", "B": "lightgray"},
    highlight_residues=highlight,
    chain_transparency={"A": 0.2},
    output_prefix=str(output_dir / "compare"),
)

image_file = portein.Pymol(
    protein=protein_config,
    layers=[
        portein.PymolConfig(
            representation="cartoon",
            pymol_settings=pymol_settings,
            selection="all",
        ),
    ],
    buffer=2,
).run()

Crop and display

cropped = portein.crop_to_content(Image.open(image_file))

DPI = 100
fig, ax = plt.subplots(figsize=(cropped.width / DPI, cropped.height / DPI), dpi=DPI)
ax.imshow(cropped)
ax.axis("off")
fig.subplots_adjust(left=0, right=1, top=1, bottom=0)
plt.show()
